◆ JY Series unloading oil measure equipments from the tank
◆Technical Specification
|
Accuracy |
0.2%. 0.5% |
|
Nominal Pressure |
PN1.0-2.5Mpa |
|
Nominal Diameter |
DN40mm.50mm.80mm.100mm |
|
Medium |
Diesel, kerosene, gasoline and so on. |
|
Working Temperature |
-45℃ ~ +60℃ |
|
WorkingState |
Using pump to add pressure, 10 tons oil will be finished in 40 minutes. |
◆Components:
Flow meter (all kinds of flow meter, with reset zero, sensor, totalizer according to you request.)
Air-removed filter (separate and eliminate gas in the gasoline, kerosene, diesel and other mixed liquid. Improve the Accuracy.)
According to the customer need, we can match the pump and motor.
Fixed equipments.( metal holder or fixed on a go-cart)
◆Features & Benefits
High-accuracy and low-noise.
Simple frame and convenience-use
Display counter with reset zero and sensor.
Fixed style or moving style.
Many components have compatibility, in size, flanges and so on.
